Description
RT52 series thermostat, designed to be used in underfloor heating system, is to control the temperature of indoor room according to the preset temperature values. The screen is acrylic with touch buttons. Simple and elegant design make it perfect for any style of decor. There are four models for option, meeting the requirements of different floor heating systems, electric floor heating or hydronic floor heating system. The product is able to set four time periods in a day: period of waking up, leaving home, back home and sleeping. This helps to tailor a comfort home according to your need and achieve energy saving.
The operation is simple. Many setting interfaces can be entered by pressing one or two designated buttons for 5 seconds.
RT52 WiFi models enable you to control the room temperature anytime and anywhere, and to upgrade the software online. The APP is Tuya Smart, free to download, and available in both IOS and Android phones.
Features
-Touch buttons, 3.5 inch screen
-Weekly programmable, customize your own schedule
-Window open detection, energy saving
-Preheat function, able to reach next time period setting in advance
-Child lock, avoid misoperation from child
-Easy operation
-WiFi control, adjust room temperature anytime and anywhere
Technical data
Voltage: AC220V/AC230V 50Hz
Rated power:＜1.5W
Terminal blocks: one terminal can be connected to
2*1.5mm² or 1*2.5mm² wire at most.
Signal terminal: 0.75mm²wire
Temperature range: 5~90℃
Measuring range: -9.5~99.5℃
Protection class: IP20
Ambient temperature: -10~55℃
Selection table
| Model | Load | Function |
| RT52.13 | 3A | hydronic heating |
| RT52.23i | 3A | hydronic heating Wi-Fi |
| potential free output | ||
| RT52.36 | 16A | electric heating time control external sensor |
| RT52.36i | 16A | external sensor time control external sensor Wi-Fi |
| Attribute | Value |
|---|---|
| Model NO. | RT52.23i |
| Product Name | Floor Heating Thermostat |
| Model | RT52.23i |
| Rated Power | <1.5W |
| Measuring Range | -9.5-99.5°C |
| Ambient Temperature | -10-55°C |
| Sample | Accept |
| MOQ | Low MOQ |
| Specification | Standard Specifications or Customized |
| Origin | Zhejiang, China |
| Display Type | LED |
| Keywords | Thermostat & Temperature Controller |
| Voltage | AC220V/AC230V 50Hz |
| Temperature Range | 5-90°C |
| Protection Class | IP20 |
| Logo Custom | Accept |
| Payment | T/T, L/C, Western Union |
| Transport Package | Standard Packaging or Customized |
| Trademark | MENRED |
| Production Capacity | 50000 pieces/Year |
