Specification
|
Outer Diameter
|
Wall Thickness
|
Pipe Series
|
Application Class
|
Meters
|
|
16×2.0
|
16
|
2.0
|
S4
|
Class4/8bar
|
400
|
|
20×2.0
|
20
|
2.0
|
S5
|
Class4/6bar
|
300
|
|
20×2.3
|
20
|
2.3
|
S4
|
Class4/8bar
|
300
|
|
25×2.3
|
25
|
2.3
|
S5
|
Class4/6bar
|
100
|
|
25×2.8
|
25
|
2.8
|
S4
|
Class4/8bar
|
100
|
|
32×2.9
|
32
|
2.9
|
S5
|
Class4/6bar
|
50
|
|
32×3.6
|
32
|
3.6
|
S4
|
Class4/8bar
|
50
|
|
Specification
|
16×2.0
|
20×2.3
|
|
Nominal Outer Diameter
|
16
|
20
|
|
Nominal Wall Thickness
|
2.0
|
2.3
|
|
Applicable Conditions and Working Pressure
|
Class4 / 8bar
|
Class4 / 8bar
|
|
Oxygen Barrier Layer Thickness
|
80μm
|
80μm
|
|
Meters/Coil
|
400m
|
300m
|
|
Specification
|
Nominal Outer Diameter
|
Nominal Wall Thickness
|
Applicable Conditions and Working Pressure
|
Oxygen Barrier Layer Thickness
|
Meters/Coil
|
|
10×1.2
|
10
|
1.2
|
Class4/8bar
|
100um
|
480
|
|
12×1.5
|
12
|
1.5
|
Class4/8bar
|
100um
|
480
|
|
14×1.8
|
14
|
1.8
|
Class4/8bar
|
100um
|
360
|
|
16×2.0
|
16
|
2.0
|
Class4/8bar
|
100um
|
480
|
|
20×2.3
|
20
|
2.3
|
Class4/8bar
|
100um
|
360
|
|
25×2.8
|
25
|
2.8
|
Class4/8bar
|
100um
|
60
|
