The MENRED G7 is a wall-mounted full heat recovery ventilator for residential applications. It has a rated airflow of 350 m³/h and a maximum airflow of 450 m³/h. G4 HEPA filtration with Toray filter media and a built-in air quality sensor support filtered air supply and indoor air monitoring. The listed heating efficiency is 73%, and the cooling efficiency is 65.5%.
Designed for residential ventilation, the G7 supplies fresh air and removes stale indoor air through a ducted system. Its built-in air quality sensor monitors indoor air conditions, and the touch-screen control interface supports day-to-day operation. Ductwork connection is available for centralized air distribution.
| Specification | Details |
|---|---|
| Model | G7 |
| Type | Wall-mounted full heat recovery ventilator |
| Power supply | 220–240 V~ 50/60 Hz |
| Rated airflow | 350 m³/h |
| Maximum airflow | 450 m³/h |
| Motor / fan | EC fan |
| Product dimensions | 940 × 630 × 405 mm |
| Maximum / rated power | 220 / 130 W |
| Supply static pressure | 80 Pa |
| Exhaust static pressure | 50 Pa |
| Heating efficiency | 73% |
| Cooling efficiency | 65.5% |
| Fresh air volume | 334 m³/h |
| Fresh air ratio | 98.2% |
| Filter | G4 HEPA |
| Filter media | Toray |
| PM2.5 filtration | 98% |
| Noise | 39 dB(A) |
| Fresh air energy consumption | 0.37 W/(m³/h) |
| Built-in sensor | Air quality sensor |
| Applicable area | Up to approximately 200 m² |
| Operating temperature | −15°C to 50°C |
| Ductwork connection | Available |
| Weight | 57 kg |
The listed rated airflow is 350 m³/h, and the maximum airflow is 450 m³/h.
The listed heating efficiency is 73%, and the cooling efficiency is 65.5%.
It uses G4 HEPA filtration with Toray filter media. The listed PM2.5 filtration efficiency is 98%.
Yes. The G7 has a built-in air quality sensor that monitors indoor air conditions.
The listed applicable area is up to approximately 200 m².
Ductwork connection is available. The listed supply static pressure is 80 Pa, and exhaust static pressure is 50 Pa.
The listed operating temperature range is −15°C to 50°C.
Contact MENRED to discuss the G7, its air quality monitoring, or your residential ventilation project.
